NXP i.MX8M Mini-1.6GHz
EBOX-IMX8MM

4S/3U/HDMI/2LAN/AUDIO/BT&WLAN/12~36V

  • NXP i.MX8MMini 1.6GHz
  • 1GB
  • 2GB
  • 4GB
  • RS-232
  • RS-485
  • USB
  • GLAN
  • Audio
  • HDMI
  • 12V~36V

Specifications

  • NXP i.MX8M Mini-1.6GHz

  • 1GB/2GB/4GB LPDDR4 onboard

  • 4S/3U/HDMI/2LAN/AUDIO/BT&WLAN

  • Operation Temperature: -0 ~ +60°C / -40 ~ +80°C (Optional)

  • eMMC: 8GB to 64GB MLC/SLC onboard

  • SD Card: SD Card Slot x1 (Internal Slot Optional)

  • VESA 100mm x 100mm/DIN Rail Support (Optional)

  • HDMI 1.3 (max. 1920 x 1080 pixels)

  • Android 9 & Yocto Ready

Manual

Datasheet

Technical Resource

Processor NXP i.MX8M Mini Quad-core 1.6 GHz ARM Cortex-A53 processors
Memory 1GB to 4GB LPDDR4 onboard
HDMI HDMI 1.3 (MAX.1920 x 1080 pixels)
Ethernet RJ45 x2 (Intel I1210 GbE x1/CPU GbE x1)
USB USB 2.0 x3 (Front x2 + Rear x1)
HD Audio Mic-in & Line-out (WM8960)
SD card slot SD Slot x1 (Internal slot Optional)
Extension I/F 8GB to 64GB eMMC MLC/SLC onboard
Extension I/F WiFi 802.11b/g/n & BT4.1 Combo 2.4G (Broadcom 43438)
RS-232 D-Sub 9-pin connector x2 or x4 ports
RS-485 D-Sub 9-pin connector x2 ports
Power requirement DC +12V~+36V
Dimensions 115 x 115 x 35mm/DIN Rail Support (Optional)
Net Weight 700g
Operation Temperature 0 ~ +60℃/-40 ~ +80℃
Certifications CE, FCC, VCCI
OS Support Android 9, Yocto, Mainline Linux Kernel Support
Model Type CPU DRAM eMMC MLC/SLC LAN D-Sub 9-pin I/O WiFi/BT Temperature
EB 8MM
(NXP i.MX8M Mini)
1: 1GB 08: 8GB M:
MLC
L1:
LAN x1
C2:
RS-232 x2/Console x1
B:
Included
N:
0~60℃
      2: 2GB 16: 16GB S: SLC
(eMMC)
L2:
LAN x2
C4:
RS-232 x4/(No Console (*))
N:
Excluded (*)
W:
-40~+80℃
      3: 3GB 32: 32GB       F2:
RS-232/RS-485 x2 (No Console*))

      4: 4GB 64: 64GB       F4:
RS-485 x2/Console x1


The EBOX-IMX8MM is a solid light-weight aluminum box PC-driven by NXP i.MX8M Mini Quad-Core 1.6GHz Cortex-A53 processor. Weigh 700g with dimension 115 x 115 x 35mm. DIN Rail & VESA Mounting capability makes it easy to be deployed in any location. Wide temperature -40°C to 80 °C support makes it good in harsh environment usage. A perfect platform for IoT, M2M, Home Automation, Network security, Point-of-Sales, Digital signage, and many other industrial applications.
