Typical PC/104 SBC: The VDX3-6754 supports Full ISA, RS-232/485, and Dual Displays

May 20, 2022

The VDX3-6754 is the most typical PC/104 form factor SBC in ICOP and implements the DM&P dual-core Vortex86 DX3 processor. Promote a Single Board Computer that natively supports full ISA with backward compatibility to provide a migration path for projects facing end-of-life challenges with their existing x86-based PC/104 controller.


The VDX3-6754 is suitable for data acquisition, industrial automation, process control, automotive controller, AVL, intelligent vehicle management device, medical device, human-machine interface, robotics, machinery control, and more.
In addition, the VDX3-6754 family of controllers is designed as a plug-in replacement, with backward compatibility to support legacy software to help extend the existing product life cycle without heavy re-engineering.

Industrial-grade SBC: VDX3-6754

The VDX3-6754 complies with industrial-grade and isolated protection:

  • Two RS-232 interfaces are fully isolated against overvoltage of up to 2.5kV for both power and signal lines.
  • The RS-485 is protected against electrostatic discharge (ESD) of +/- 15kV.
  • Environmental working temperature ranges from -20 to +70 C standard with the extended temperature of -40 to +85 C optionally.
  • The DRAM is soldered directly onboard for resistance to vibrations and shock.


The VDX3-6754 also supports the dual-display with VGA and LVDS output, from the DM&P Vortex86 DX3 SoC graphics supports a HD resolution of 1920x1080 at 60Hz for 24-bit LVDS.

The Vortex86 DX3 line of CPUs also support a wide range of operating systems - DOS, Windows CE (6.0, 7.0), Windows 7, WES7, Windows XP Professional, Windows Embedded Standard (XPe), POS Ready (WePOS), Embedded Linux, X-Linux, QNX (BSP), VxWorks (BSP), and FreeBSD.

Main features of VDX3-6754:

  • DM&P SoC Vortex86DX3- 1GHz
  • 1GB / 2GB DDR3 onboard
  • 4S / 2U / VGA / LCD / LVDS / LAN / LPT / Audio / 16GPIO / SATA
  • Operation Temperature: -20 ~ +70°C / -40 ~ +85°C (Optional)

For more info and sample request, please write to, call your nearest ICOP Branch, or contact our Worldwide Official Distributor.
